QJ1000 Series
  • QJ1000 Series
  • QJ1000 Series

Download Catalog

Angular contact ball bearings have inner and outer ring raceways that are displaced relative to each other in the direction of the bearing axis. This means that these bearings are designed to accommodate combined loads, i.e. simultaneously acting radial and axial loads.

The axial load carrying capacity of angular contact ball bearings increases as the contact angle increases. The contact angle is defined as the angle between the line joining the points of contact of the ball and the raceways in the radial plane, along which the combined load is transmitted from one raceway to another, and a line perpendicular to the bearing axis

The most commonly used designs are:

single row angular contact ball bearings

double row angular contact ball bearings

four-point contact ball bearings


>>
<<
SelectInquiryDesignationPrincipal dimensions(mm)Basic load ratings(KN)Basic load ratings(kgf)Limiting Speed (rpm) Distance of action pointInstallation dimensions(mm) Weight
dDBr(min)CrCorCrCorGreaseOila0(mm)da(min)Da(max)ra(max)(kg)
QJ1016 80 125 22 1.1 77000 167000 7850 17000 3800 5300 71.8 87 118 1 1.05
QJ1017 85 130 22 1.1 79000 176000 8050 18000 3800 5000 75.3 92 123 1 1.1
QJ1018 90 140 24 1.5 94000 208000 9600 21200 3400 4800 80.5 99 131 1.5 1.45
QJ1019 95 145 24 1.5 96500 220000 9800 22500 3400 4500 84 104 136 1.5 1.5
>>
<<
